Scale Option − 30” Litter with Stationary Foot Section
136
Item Part No. Part Name Qty.
A 1070−137−001 Flange Eyelet 2
B 0013−038−000 External Tooth Lock Washer 1
C 0025−120−000 Rivet 2
D 0785−010−353 Foot End Cover, Scales 1
E 1070−010−341 Bracket 1
F(page 140) Head End Lift Header 1
G(page 141) Foot End Lift Header 1
H 1070−037−903 Specification Label 1
J 1070−137−902 Scale Usage Label 1
K(page 142) Scale Display Assembly 1
L 3000−300−113 Cable Tie 13
M 0025−079−000 Rivet 2
N 0946−001−155 Bumper 2
P 0023−288−000 Hex Washer Hd. Screw 2
