Scale Option − 26” Litter with Stationary Foot Section
128
Item Part No. Part Name Qty.
A 0013−038−000 Ext. Tooth Lock Washer 1
B 0023−288−000 Hex Washer Hd. Screw 2
C 0025−079−000 Rivet 2
D 0025−120−000 Rivet 2
E 0785−010−653 Foot End Cover 1
F 0946−001−155 Bumper 2
G 1070−010−641 Bracket 2
H(page 132) Head End Lift Header 1
J(page 133) Foot End Lift Header 1
K 1070−037−903 Specification Label 1
L 1070−137−001 Flange Eyelet 2
M 1070−137−902 Scale Usage Label 1
N(page 142) Scale Display Assembly 1
P 3000−300−113 Cable Tie 13
