Stryker M Series Maintenance Manual

Base Labeling Assembly − 4−Side Brakes/3−Side Hydraulics
64
Color
Set P/N
Item F
Lift/Lower, Left
Item G
Lift/Lower, Right
Item J
BrakeSteer, F/E
Item K
BrakeSteer, H/E
Item M
Pump Pedal, F/E
YELLOW
1005−224−401
0853−024−301 0853−024−401 0785−024−600 0785−024−700 0785−024−501
GRAY
1005−224−402
0853−024−302 0853−024−402 0785−024−600 0785−024−700 0785−024−502
LIGHT BLUE
1005−224−403
0853−024−303 0853−024−403 0785−024−600 0785−024−700 0785−024−503
RED
1005−224−405
0853−024−305 0853−024−405 0785−024−600 0785−024−700 0785−024−505
PURPLE
1005−224−407
0853−024−307 0853−024−407 0785−024−600 0785−024−700 0785−024−507
NAVY
1005−224−408
0853−024−308 0853−024−408 0785−024−600 0785−024−700 0785−024−508
TEAL
1005−224−409
0853−024−309 0853−024−409 0785−024−600 0785−024−700 0785−024−509
GREEN
1005−224−410
0853−024−310 0853−024−410 0785−024−600 0785−024−700 0785−024−510
Color
Set P/N
Item N
Lowering, F/E.
Item R
Trend, Left
Item H
Stryker Logo
Item L
Litter Stripe
Item T
700 lb. Capacity
YELLOW
1005−224−401
0853−024−901 0853−024−951 0853−024−801 0785−022−101 0785−023−050
GRAY
1005−224−402
0853−024−902 0853−024−952 0853−024−802 0785−022−102 0785−023−050
LIGHT BLUE
1005−224−403
0853−024−903 0853−024−953 0853−024−803 0785−022−103 0785−023−050
RED
1005−224−405
0853−024−905 0853−024−955 0853−024−805 0785−022−105 0785−023−050
PURPLE
1005−224−407
0853−024−907 0853−024−957 0853−024−807 0785−022−107 0785−023−050
NAVY
1005−224−408
0853−024−908 0853−024−958 0853−024−808 0785−022−108 0785−023−050
TEAL
1005−224−409
0853−024−909 0853−024−959 0853−024−809 0785−022−109 0785−023−050
GREEN
1005−224−410
0853−024−910 0853−024−960 0853−024−810 0785−022−110 0785−023−050
