26” Knee Gatch Assembly
95
Item Part No. Part Name Qty.
A 0016−036−000 Nylock Hex Nut 3
B 0023−288−000 Hex Washer Hd. Screw 3
C 0023−310−000 Pan Hd. Torx Screw 2
D 0025−079−000 Rivet 3
E 8805−932−000 Clevis Pin 1
F 0027−020−000 Rue Ring Cotter 1
G 0785−014−030 Gatch Pivot 1
H(page 98) Gatch Valve Body Assembly 1
J 0785−014−081 Snap Bushing 1
K 0785−014−107 Gatch Return Spring 1
L 0785−014−113 Gatch Pump Bumper 1
M(page 100) Gatch Pump Assembly 1
N 0785−014−133 Gatch Pivot Spacer 1
P 0785−014−156 Gatch Pump Handle, Left 1
R 0785−014−157 Gatch Pump Handle, Right 1
S(page 101) Gatch Release Handle 1
T 0785−014−625 Gatch Weldment 1
V 0785−114−027 Gatch Release Handle 1
