Specifications 51
Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
The Dual Channel SmartPump is intended for use in the electromagnetic environment specified below. The customer or
the user of the Dual Channel SmartPump should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment -
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
+6 kV contact
+
8 kV air
+2, 4, 6 kV contact
+
2, 4, 8 kV air
Floors should be wood, concrete, or
ceramic tile. If floors are covered with
synthetic material, the relative humidity
should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
+2 kV for power
supply lines
+
1 kV for
input/output lines
+2 kV for power supply
lines
Mains power quality should be that of
a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
+1 kV differential
mode
+
1 kV for
input/output lines
+0.5, 1 kV differential
mode
+
0.5, 1, 2 kV common
mode
Mains power quality should be that of
a typical commercial or hospital
environment.
Voltage dips, short
interruptions, and
voltage variations on
power supply input
lines
IEC 61000-4-11
<5% U
T
(>95% dip in U
T
)
for 0,5 cycle
<40% U
T
(>60% dip in U
T
)
for 5 cycles
<70% U
T
(>30% dip in U
T
)
for 25 cycles
<5% U
T
(>95% dip in U
T
)
for 5 cycles
95% Reduction
(10 ms)
60% Reduction
(100 ms)
30% Reduction
(500 ms)
95% Reduction
(5 s)
Mains power quality should be that of
a typical commercial or hospital
environment. If the user of the Dual
Channel SmartPump requires
continued operation during power
mains interruptions, it is recommended
that the Dual Channel SmartPump be
powered from an uninterruptible power
supply or a battery.
Power frequency
(50/60 Hz) magnetic
field
IEC 61000-4-8
3 A/m 3 A/m
50/60 Hz
Power frequency magnetic fields
should be at levels characteristic of a
typical location in a typical commercial
or hospital environment.
NOTE: U
T
is the alternating current mains voltage prior to application of the test level.
