Stryker SmartPump Rx - Display Screen

Control Panel and Display 15
Display Screen
Areas of the SmartPump display screen are illustrated below.
See Display Indicators.
Battery Charge
Indicator
Actual Cuff
Pressure
220 mmHg
Pressure Gauge:
Indicating cuff at
target pressure
System Ready
Indicator
IVRA Lock
Status: Unlocked
Inflation Timer:
Indicating elapsed
time: 50 minutes
(Time displayed in
hours and minutes
format)
Active Cuff
Cuff 1
Ready Cuff
Cuff 2
Default Settings:
Time: 1 hour
Pressure: 250 mmHg
