Studer OnAir 3000 Service Instructions

2-31
Date printed: 28.02.11
OnAir 3000 Digital Mixing Console
SCore Host Card A943.032585
Page: 1 of 3
Date printed: 02.03.2011
Rev RefDes Order no. Qty Value Description
0 B1 C089.012204 1 CR2032 BATTERY 3V 190MAH LITHIUM COIN
0 C1 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C2 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C4 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C5 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C6 C059.602233 1 22p CAP SM CER 22PF 5% 50V NPO 0603
0 C7 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C8 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C9 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C10 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C11 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C12 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C13 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C14 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C15 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C16 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C17 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C18 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C19 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C20 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C21 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C22 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C23 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C24 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C25 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C26 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C27 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C28 C059.680031 1 220u CAP SM ELC 220UF 6.3V 85°C
0 C29 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C30 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C31 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C32 C059.602235 1 27p CAP SM CER 27PF 5% 50V NPO 0603
0 C33 C059.602235 1 27p CAP SM CER 27PF 5% 50V NPO 0603
0 C34 C059.602235 1 27p CAP SM CER 27PF 5% 50V NPO 0603
0 C35 C059.602235 1 27p CAP SM CER 27PF 5% 50V NPO 0603
0 C36 C059.602235 1 27p CAP SM CER 27PF 5% 50V NPO 0603
0 C37 C059.602235 1 27p CAP SM CER 27PF 5% 50V NPO 0603
0 C38 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C39 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C40 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C41 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C42 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C43 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C50 C059.680029 1 100u CAP SM ELC 100UF 6.3V 85°C
0 C51 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C52 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C53 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C54 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C55 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C56 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C57 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C58 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C59 C059.680065 1 10u CAP SM ELC 10UF 16V 85°C
0 C60 C059.680065 1 10u CAP SM ELC 10UF 16V 85°C
0 C62 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C63 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C66 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C67 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C68 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C69 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C70 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C71 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C72 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C73 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C74 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C75 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C76 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C77 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C78 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C80 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C81 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C82 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C83 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C84 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C85 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C86 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C87 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C88 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C89 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
Rev RefDes Order no. Qty Value Description
0 C90 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C91 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C92 C059.680065 1 10u CAP SM ELC 10UF 16V 85°C
0 C93 C059.680065 1 10u CAP SM ELC 10UF 16V 85°C
0 D1 C050.608001 1 LL4448 DSL LL4448
0 D2 C050.608001 1 LL4448 DSL LL4448
0 D7 C050.608001 1 LL4448 DSL LL4448
0 D8 C050.608001 1 LL4448 DSL LL4448
0 D9 C050.608001 1 LL4448 DSL LL4448
0 D10 C050.608001 1 LL4448 DSL LL4448
0 D11 C050.608001 1 LL4448 DSL LL4448
0 D12 C050.608001 1 LL4448 DSL LL4448
0 D13 C050.608001 1 LL4448 DSL LL4448
0 D14 C050.608001 1 LL4448 DSL LL4448
0 DL1 C050.609412 1 red SMD LED RED LST670-LM 2.7X3.5
0 DL4 C050.042806 1 grn LED BARGRAPH GRN 10SEG DIP
0 DL5 C050.042771 1 grn LED GREEN 2-TIER 10MA R
\
A
NG.PCB
0 DL6 C050.042750 1 red LED RED 10MA R/ANG PCB MTG
0 IC1 C050.623000 1 74HCT IC 74HCTD 4X2I/P NAND CMOS
0 IC2 C050.630203 1 TL16C550C IC TL16C550C UART AUTOFLOW CNTRL
0 IC3 C050.630214 1 PCA9564 PAR-I2C BUS CNTRL
0 IC5 C050.623000 1 74HCT IC 74HCTD 4X2I/P NAND CMOS
0 IC6 C050.620463 1 DS34C86 LINE RCVR RS-422 QUAD
0 IC7 C050.620464 1 DS34C87 QUAD DRVR RS-422
0 IC8 C050.621008 1 74HC8 IC MC74HC8A 4X2I/P AND CMOS
0 IC9 C050.630203 1 TL16C550C IC TL16C550C UART AUTOFLOW CNTRL
0 IC11 C050.620467 1 MAX232 IC MAX232A DUAL RS232 TCVR
0 IC12 C050.630213 1 PCI6150 32BIT PCI/PCI BRDG 66MHZ
0 IC16 C050.621032 1 74HC32 IC MC74HC32A 4X2I/P OR CMOS
0 IC17 C050.621157 1 74HC157 IC MM74HC157 4X2I/P MPLXCMOS
0 IC18 C050.621157 1 74HC157 IC MM74HC157 4X2I/P MPLXCMOS
0 IC19 C050.621000 1 74HC IC 74HCD 4X2I/P NAND CMOS
0 IC20 C050.623138 1 74HCT138 IC 74HCT138D 3:8 LINE DECDR
0 IC21 C050.623138 1 74HCT138 IC 74HCT138D 3:8 LINE DECDR
0 IC22 C050.623138 1 74HCT138 IC 74HCT138D 3:8 LINE DECDR
0 IC23 C050.621157 1 74HC157 IC MM74HC157 4X2I/P MPLXCMOS
0 IC24 C050.623138 1 74HCT138 IC 74HCT138D 3:8 LINE DECDR
0 IC25 C050.623138 1 74HCT138 IC 74HCT138D 3:8 LINE DECDR
0 IC26 C050.621008 1 74HC8 IC MC74HC8A 4X2I/P AND CMOS
0 IC27 C050.621273 1 74HC273 IC MM74HC273 OCTAL D-TYPE F/F + CL
R
0 IC28 C050.621032 1 74HC32 IC MC74HC32A 4X2I/P OR CMOS
0 IC29 C050.621032 1 74HC32 IC MC74HC32A 4X2I/P OR CMOS
0 IC30 C050.623000 1 74HCT IC 74HCTD 4X2I/P NAND CMOS
0 IC31 C050.621008 1 74HC8 IC MC74HC8A 4X2I/P AND CMOS
0 IC32 C050.623138 1 74HCT138 IC 74HCT138D 3:8 LINE DECDR
0 IC33 C050.621273 1 74HC273 IC MM74HC273 OCTAL D-TYPE F/F + CL
R
0 L2 C062.600903 1 HF BEAD FERRITE 600R 0.1
A
0 L3 C062.600903 1 HF BEAD FERRITE 600R 0.1
A
0 L4 C062.600903 1 HF BEAD FERRITE 600R 0.1
A
0 L9 C062.600903 1 HF BEAD FERRITE 600R 0.1
A
0 L10 C062.600903 1 HF BEAD FERRITE 600R 0.1
A
0 L11 C062.600903 1 HF BEAD FERRITE 600R 0.1
A
0 L12 C062.600903 1 HF BEAD FERRITE 600R 0.1
A
0 MP1
A
943.032512 1 PCB SCORE CPU BOARD
0 MP2
A
943.032510 1 NR-ETIKETTE 5 * 20
0 MP3 C043.010108 1 Label LABEL - ESD CARE WARNING
1 MP4
A
943.032501 1 FRONT PANEL SCORE CPU MODEL
0 MP5
A
940.060005 1 HANDLE LEGEND PLATE - STUDER MODULES
0 MP6 C049.020514 1 4TE Ejector handle kit 4HP bottom
0 MP7 C049.020521 1 METAL BUSH-FRONT PANEL VERO
0 MP8 C049.020524 1 M2.5*12 SCREW CAPTIVE M2.5X12 FRNT PNL
0 MP9 C049.020522 1 PCB MOUNTING BRKT.METAL VERO
0 MP11 C022.324125 1 M2.5*3 NUT M2.5 RIVETED PCB TYPESTEEL.
0 MP12 C022.324125 1 M2.5*3 NUT M2.5 RIVETED PCB TYPESTEEL.
0 MP13 C022.324125 1 M2.5*3 NUT M2.5 RIVETED PCB TYPESTEEL.
0 MP14 C022.324125 1 M2.5*3 NUT M2.5 RIVETED PCB TYPESTEEL.
0 MP15
A
928.022002 1 Window
1 MP16 C089.200303 1 2 (4) GB MEM COMPACT FLASH CARD
0 MP17 C089.201143 1 ETX VIA Board 800 MHz
0 MP18 C050.631654 1 16M*64 MEM DRAM 16MX64 SODIMM 144
0 MP19 C022.015030 1 M3 NUT M3 BZPCA-FIX005
0 MP20 C024.162030 1 3.2/6.0 WSHR M3 EXT S/PROOF ST/STL DIN6798
0 MP21 C054.130083 1 4.85mm SCRW LOCK M3XUNC4-40 F/MALE
0 MP22 C024.161030 1 3.2/5.5 WSHR M3 Serrated Safety Washer 'S' Type
0 MP23 C027.100312 1 M3*12 SPCR M3X12MM ML/FML SZP
0 MP24 C021.539354 1 M3*6 SCRW M3X6MM HEX/HD SKT S/LOCK BNP
0 MP25
A
943.032505 1 KueHLKoeRPER NACHARBEIT
0 P1 C054.201001 1 RJ45_8 SKT JACK RJ45 8WY R/A PCB/MNT
0 P2 C054.201103 1 USB-
A
_Dual CON DUAL USB TYPE A SKT R/A PCB/MNT
