Studer OnAir 3000 Service Instructions

2-39
Date printed: 28.02.11
OnAir 3000 Digital Mixing Console
SCore Audio Clock Card A943.033024
Page: 1 of 2
Date printed: 02.03.2011
Rev RefDes Order no. Qty Value Description
0 C1 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C2 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C3 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C4 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C5 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C6 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C7 C059.602365 1 470p CAP SM CER 470PF 5% 50V NPO 0805
0 C8 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C9 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C11 C059.602249 1 100p CAP SM CER 100PF 5% 50V NPO 0603
0 C12 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C13 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C14 C059.603323 1 6n8 CAP SM CER 6.8NF 10% 50VX7R 0805
0 C15 C059.603335 1 68n CAP SM CER 68NF 10% 50V X7R 0805
0 C16 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C17 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C18 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C19 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C20 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C21 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C22 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C23 C059.603901 1 10n CAP SM CER 10NF 10% 16V X7R 0402
0 C24 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C25 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C26 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C27 C059.603903 1 1u CAP SM CER 1.0UF 20% 6.3V X5R 0603
0 C28 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C29 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C30 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C31 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C32 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C33 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C34 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C35 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C36 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C37 C059.603321 1 4n7 CAP SM CER 4.7NF 10% 50VX7R 0805
0 C38 C059.602229 1 15p CAP SM CER 15PF 5% 50V NPO 0603
0 C39 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C40 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C42 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C46 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C47 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C48 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C49 C059.602229 1 15p CAP SM CER 15PF 5% 50V NPO 0603
0 C50 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C51 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C52 C059.603903 1 1u CAP SM CER 1.0UF 20% 6.3V X5R 0603
0 C53 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C54 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C55 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C56 C059.603901 1 10n CAP SM CER 10NF 10% 16V X7R 0402
0 C57 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C58 C059.603903 1 1u CAP SM CER 1.0UF 20% 6.3V X5R 0603
0 C59 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C60 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C61 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C62 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C63 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C64 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C65 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C66 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C67 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C68 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C69 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C70 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C71 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C73 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C74 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C75 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C76 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C77 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C79 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C80 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C81 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C82 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C83 C059.603329 1 22n CAP SM CER 22NF 10% 50V X7R 0805
0 C84 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C85 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C87 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
Rev RefDes Order no. Qty Value Description
0 C88 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C89 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C90 C059.680031 1 220u CAP SM ELC 220UF 6.3V 85°C
0 C91 C059.602373 1 1n CAP SM CER 1.0NF 5% 50V NPO 0805
0 C92 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C93 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C94 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C95 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C97 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C98 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C99 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C100 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C101 C059.603325 1 10n CAP SM CER 10NF 10% 50V X7R 0805
0 C102 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C103 C059.603903 1 1u CAP SM CER 1.0UF 20% 6.3V X5R 0603
0 C104 C059.603904 1 10u CAP SM CER 10UF 20% 6.3VX5R 0805
0 C105 C059.603321 1 4n7 CAP SM CER 4.7NF 10% 50VX7R 0805
0 C106 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 D1 C050.608901 1 BAV99 DHS BAV99
0 D2 C050.608003 1 S1B DRC S1B 100V 1
A
0 D3 C050.608003 1 S1B DRC S1B 100V 1
A
0 D4 C050.608901 1 BAV99 DHS BAV99
0 D5 C050.608901 1 BAV99 DHS BAV99
0 D6 C050.608901 1 BAV99 DHS BAV99
0 D7 C050.608003 1 S1B DRC S1B 100V 1
A
0 D8 C050.608003 1 S1B DRC S1B 100V 1
A
0 DL1 C050.609417 1 grn LED GREEN DIFFUSED TOP SMD
0 IC1 C050.628053 1 74HC4053 IC 74HC4053 3X2CH DMPLX/MPLX ANLOG
0 IC2 C050.612003 1 LM1117DT VOLT REG 1.25V/13.8V 0.8
A
0 IC3 C050.610205 1 TS272 DUAL OP-
A
MP
0 IC4 C089.011510 1 19.2MHz XTAL 19.2MHZ VXCO DIP14
0 IC6 C050.632002 1 MAX6358 DUAL VOLT MPU SPVRY RST
0 IC7 C050.650244 1 74LVC244 IC 74LVC244AD OCTAL BFFR/LDRVR
1 IC8 S943.095422 1 Claudio SW 330 Claudio V2.2 ISP
0 IC9 C050.620302 1 EL4511 SYNC SEPERATO
R
0 IC10 C050.624946 1 74HCT9046 IC 74HCT9046A PLL BANDGAP VCO
0 IC11 C050.619001 1 LM393 DUAL VOLT CMPARTR
0 IC12 C050.623541 1 74HCT541 IC 74HCT541D OCTAL BFFR/LDRVR 3ST
0 IC13 C050.634217 1 EP1C3 FPGA 2910 LE TQFP-144
0 IC14 C050.621904 1 74HCU04 IC 74HCU04 HEX INVTR UNBUFFD CMOS
0 IC15 C050.620469 1 DS90LV011 3V LVDS SNGL HIGH SPEED
0 IC16 C050.620463 1 DS34C86 LINE RCVR RS-422 QUAD
0 IC17 C050.620469 1 DS90LV011 3V LVDS SNGL HIGH SPEED
0 IC18 C050.620469 1 DS90LV011 3V LVDS SNGL HIGH SPEED
0 IC19 C050.620469 1 DS90LV011 3V LVDS SNGL HIGH SPEED
0 IC20 C050.623541 1 74HCT541 IC 74HCT541D OCTAL BFFR/LDRVR 3ST
0 IC22 C050.650244 1 74LVC244 IC 74LVC244AD OCTAL BFFR/LDRVR
0 IC23 C050.623541 1 74HCT541 IC 74HCT541D OCTAL BFFR/LDRVR 3ST
0 IC24 C050.612003 1 LM1117DT VOLT REG 1.25V/13.8V 0.8
A
0 IC26 C050.623541 1 74HCT541 IC 74HCT541D OCTAL BFFR/LDRVR 3ST
0 IC27 C050.623540 1 74HCT540 IC 74HC540 OCTAL BFFR/LDRVR 3ST
0 IC28 C050.620920 1 CS8416 CS8416 DIG AUDIO TCVR 192KHZ
0 IC29 C050.620260 1 TLC2932 HIGH PERF PLL
0 IC30 C050.620260 1 TLC2932 HIGH PERF PLL
0 IC31 C050.612003 1 LM1117DT VOLT REG 1.25V/13.8V 0.8
A
0 L1 C062.600113 1 10u INDCT SM 10uH 10% 140MA
0 L2 C062.600113 1 10u INDCT SM 10uH 10% 140MA
1 MP1
A
943.033014 1 PCB SCORE AUDIO CLOCK
0 MP2
A
943.033010 1 NR-ETIKETTE 5 * 20
0 MP3 C043.010108 1 Label LABEL - ESD CARE WARNING
0 MP4 C028.990119 1 RIVT 2.5MMX9MM BRASS TUBE
0 MP5 C024.162025 1 2.7/5.5 WSHR M2.5 EXT S/PROOF STEEL
0 MP6 C054.130081 1 4.85mm SCREWLOCK FML 4.8MM/12.7MM
1 MP10
A
943.033001 1 FRONT PANEL AUDIO CLOCK MODULE
0 MP11
A
940.060005 1 HANDLE LEGEND PLATE - STUDER MODULES
0 MP12 C049.020514 1 4TE Ejector handle kit 4HP bottom
0 MP13 C049.020521 1 METAL BUSH-FRONT PANEL VERO
0 MP14 C049.020524 1 M2.5*12 SCREW CAPTIVE M2.5X12 FRNT PNL
0 MP101 C050.609420 1 d3*7 LIGHTPIPE 3MM DIA.SPHERICAL.
0 P1 C054.212019 1 BNC CON BNC SKT 50R R/ANG PCB MTG
0 P2 C054.142001 1 Latch_10 CON 10WY ML IDC LO/PRF V/MNT
0 P4 C054.212019 1 BNC CON BNC SKT 50R R/ANG PCB MTG
0 P5 C054.112261 1 Euro_48 CON 48WAY PLUG DIN41612 ABC R/A PCB
MTG
0 P6 C054.212019 1 BNC CON BNC SKT 50R R/ANG PCB MTG
0 P7 C054.130072 1 DSUB_15 CON 15WY FML D-TYPE R/A S/LCK
1 R1 C057.601472 1 4k7 RES SM 4K7 1% 0.25W MINIMELF 50PPM 0204
0 R2 C057.691047 1 82E R 82, 5%, CHIP 0603
1 R3 C057.601472 1 4k7 RES SM 4K7 1% 0.25W MINIMELF 50PPM 0204
