Studer OnAir 3000 Service Instructions

2-43
Date printed: 28.02.11
OnAir 3000 Digital Mixing Console
SCore Time Sync Card A943.034022
Page: 1 of 1
Date printed: 02.03.2011
Rev RefDes Order no. Qty Value Description
0 C1 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C2 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C3 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C4 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C5 C059.680109 1 10u C
A
P SM ELC 10UF 35V 85°C
0 C6 C059.602373 1 1n CAP SM CER 1.0NF 5% 50V NPO 0805
0 C7 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C8 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C9 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C10 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C11 C059.603321 1 4n7 CAP SM CER 4.7NF 10% 50VX7R 0805
0 C13 C059.603321 1 4n7 CAP SM CER 4.7NF 10% 50VX7R 0805
0 C14 C059.602365 1 470p CAP SM CER 470PF 5% 50V NPO 0805
0 C15 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C16 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C17 C059.602237 1 33p CAP SM CER 33PF 5% 50V 0603
0 C18 C059.602241 1 47p CAP SM CER 47PF 5% 50V NPO 0603
0 C19 C059.602237 1 33p CAP SM CER 33PF 5% 50V 0603
0 C20 C059.602237 1 33p CAP SM CER 33PF 5% 50V 0603
0 C21 C059.680109 1 10u CAP SM ELC 10UF 35V 85°C
0 C22 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C23 C059.680109 1 10u CAP SM ELC 10UF 35V 85°C
0 C24 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C25 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C26 C059.602249 1 100p CAP SM CER 100PF 5% 50V NPO 0603
0 C27 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C28 C059.603333 1 47n CAP SM CER 47NF 10% 50VX7R 0805
0 C29 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C30 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C31 C059.680109 1 10u CAP SM ELC 10UF 35V 85°C
0 C32 C059.602249 1 100p CAP SM CER 100PF 5% 50V NPO 0603
0 C33 C059.602249 1 100p CAP SM CER 100PF 5% 50V NPO 0603
0 C34 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C35 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C36 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C37 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C38 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 C39 C059.603337 1 100n CAP SM CER 100NF 10% 50VX5R 0805
0 D1 C050.608001 1 LL4448 DSL LL4448
0 IC1 C050.619001 1 LM393 DUAL VOLT CMPARTR
0 IC2 C050.621573 1 74HC573 IC M74HC573RM D-TYPE L
A
TCH
0 IC3 S942.092828 1 (50.16.0314) SW 150 Time Sync Module
0 IC4 C050.619001 1 LM393 DUAL VOLT CMPARTR
0 IC5 C050.610205 1 TS272 DUAL OP-
A
MP
0 IC7 C050.610205 1 TS272 DUAL OP-
A
MP
0 IC8 C050.621904 1 74HCU04 IC 74HCU04 HEX INVTR UNBUFFD CMOS
0 IC9 C050.160201 1 SCC2691 IC UART DIP24 SCC2691
0 IC10 C050.620463 1 DS34C86 LINE RCVR RS-422 QUAD
0 IC11 C050.620464 1 DS34C87 QUAD DRVR RS-422
0 IC12 C050.620467 1 MAX232 IC MAX232A DUAL RS232 TCVR
0 J1 C054.110136 1 - CON 6WY HDR DIL 0.1"
0 J2 C054.110136 1 - CON 6WY HDR DIL 0.1"
0 J3 C054.110136 1 - CON 6WY HDR DIL 0.1"
0 L1
A
022.045900 1 459 Output Transformer 1:1
1 MP1
A
943.034012 1 PCB SCORE TIME SYNC.BOARD
0 MP2
A
943.034010 1 NR-ETIKETTE 5 * 20
0 MP3 C043.010108 1 Label LABEL - ESD CARE WARNING
0 MP4 C028.990119 1 RIVT 2.5MMX9MM BRASS TUBE
1 MP10
A
943.034001 1 FRONT PANEL-SCORE TIME SYNC.MOD
0 MP11
A
940.060005 1 HANDLE LEGEND PLATE - STUDER MODULES
0 MP12 C049.020514 1 4TE Ejector handle kit 4HP bottom
0 MP13 C049.020521 1 METAL BUSH-FRONT PANEL VERO
0 MP14 C049.020524 1 M2.5*12 SCREW CAPTIVE M2.5X12 FRNT PNL
0 MP15 C049.020522 1 PCB MOUNTING BRKT.METAL VERO
0 MP16 C024.162030 1 3.2/6.0 WSHR M3 EXT S/PROOF ST/STL DIN6798
0 MP17 C054.130081 1 4.85mm SCREWLOCK FML 4.8MM/12.7MM
0 MP102 C054.010021 1 Jumpe
r
JMP 2WY 0.1" GLD HONDA
0 MP103 C054.010021 1 Jumpe
r
JMP 2WY 0.1" GLD HONDA
0 MP104 C054.010021 1 Jumpe
r
JMP 2WY 0.1" GLD HONDA
0 MP105 C054.010021 1 Jumpe
r
JMP 2WY 0.1" GLD HONDA
0 MP106 C054.010021 1 Jumpe
r
JMP 2WY 0.1" GLD HONDA
0 P1 C054.130076 1 DSUB_9 CON 9WY ML D-TYPE R/A S/LCK
0 P2 C054.112261 1 Euro_48 CON 48WAY PLUG DIN41612 ABC R/A PCB
MTG
0 P3 C054.130076 1 DSUB_9 CON 9WY ML D-TYPE R/A S/LCK
0 R1 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R2 C057.691121 1 100
k
RES SM 100K 5% 0.1W 0603
1 R3 C057.601272 1 2k7 RES SM 2K7 1% 0.25W MINIMELF 50PPM 0204
0 R4 C057.691037 1 33E RES SM 33R 5% 0.1W 0603
Rev RefDes Order no. Qty Value Description
0 R5 C057.691121 1 100
k
RES SM 100K 5% 0.1W 0603
1 R6 C057.601473 1 47
k
RES SM 47K 1% 0.25W MINIMELF 50PPM 0204
0 R8 C057.601683 1 68
k
RES SM 68K 1% 0.25W MINIMELF 50PPM 0204
0 R9 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R10 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R11 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R12 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
1 R14 C057.601333 1 33
k
RES SM 33K 1% 0.25W MINIMELF 50PPM 0204
0 R15 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
1 R16 C057.601333 1 33
k
RES SM 33K 1% 0.25W MINIMELF 50PPM 0204
0 R17 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R18 C057.691121 1 100
k
RES SM 100K 5% 0.1W 0603
0 R19 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
1 R20 C057.601105 1 1M RES SM 1M0 1% 0.25W MINIMELF 50PPM 0204
1 R21 C057.601471 1 470 RES SM 470R 1% 0.25W MINIMELF 50PPM 020
3 R24 C057.601000 1 0E RES SM 0R 1% 0.25W MINIMELF 50PPM 020
3 R25 C057.601000 1 0E RES SM 0R 1% 0.25W MINIMELF 50PPM 020
0 R26 C057.927013 1 0.5
A
FUSE RESETTABLE 0.5A 60V RM5 /!
\
1 R27 C057.601103 1 10
k
RES SM 10K 1% 0.25W MINIMELF 50PPM 0204
1 R28 C057.601153 1 15
k
RES SM 15K 1% 0.25W MINIMELF 50PPM 0204
0 R29 C057.691085 1 3k3 RES SM 3K3 5% 0.1W 0603
1 R30 C057.601821 1 820 RES SM 820R 1% 0.25W MINIMELF 50PPM 020
0 R31 C057.691085 1 3k3 RES SM 3K3 5% 0.1W 0603
0 R40 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R41 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R42 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R43 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R44 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R45 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R46 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
1 R47 C057.601151 1 150 RES SM 150R 1% 0.25W MINIMELF 50PPM 020
0 R48 C057.691085 1 3k3 RES SM 3K3 5% 0.1W 0603
0 R49 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 R50 C057.691097 1 10
k
RES SM 10K 5% 0.1W 0603
0 S2 C055.600108 1 SWT SM DIL 8W LOW PROFILELE
0 XIC3 C053.030172 1 40p SKT 40WY DIL IC DUAL WIPE TIN
0 Y1 C089.601004 1 22.1184MHz CRYSTAL 22.1184MHZ 100PPM SMD.
0 Y2 C089.601008 1 3.6864MHz CRYSTAL 3.6864MHZ 100PPMSMD
