STULZ Ultra-Series Humidifier Controller
48 (August, 2013)
Customer Alarm 3 Invert Yes
Group Select Invert Yes
Parameter Set Point
Group A Limit Enable Yes
Group B Limit Enable Yes
Cabinet Temperature Alarm Shutdown No
NTC2 Temperature Alarm Shutdown No
NTC3 Temperature Alarm Shutdown No
Custom Alarm 1 Shutdown Enable No
Custom Alarm 2 Shutdown Enable No
Custom Alarm 3 Shutdown Enable No
Custom Alarm 4 Shutdown Enable No
Cabinet Low Temperature Alarm Enable Yes
Cabinet High Temperature Alarm Enable Yes
NTC2 Low Temperature Alarm Enable No
NTC2 High Temperature Alarm Enable No
NTC3 Low Temperature Alarm Enable No
NTC3 High Temperature Alarm Enable No
NTC2 Low Temperature Alarm Enable No
NTC2 High Temperature Alarm Enable No
Humidity Limit Alarm Enable No
Demo Case Selected No
Control Temperature Offset 0.0°F
Control Humidity Offset 0.0%RH
Conductivity Offset 0.0 uS
Airspeed Offset 0.0 fpm
Cabinet Temperature Offset 0.0°F
NTC2 Temperature Offset 0.0°F
NTC3 Temperature Offset 0.0°F
NTC4 Temperature Offset 0.0°F
Customer Alarm 1 Shutdown Enable No
Customer Alarm 2 Shutdown Enable No
Customer Alarm 3 Shutdown Enable No
Airflow Shutdown Enable No
Control Mode Humidity
Limit Humidity Set Point 80.0%RH
Limit Temperature Set Point 72.0°F
Startup Delay 10 Sec
Pin 4 None
Airflow Delay 5 sec
Alarm delay 10 sec
Airflow offset 0.0 fpm
dew point Cut-in -4.0°F
dew point Cutout 0.0°F
Sensor Fail Delay 15 sec
Recovery Delay 1 sec
Limit dew point Cut-in 5.0°F
Limit dew point Cutout 0.0°F
Control Password 1
Service Password 2
Factory Password -
System Configuration Password -
Number of humidifiers 1
First Modbus address of Humidifiers 6
Airspeed Type 4-20mA
High Limit Humidity Alarm Set Point 95.0%RH
Low Limit Humidity Alarm Set Point 20.0%RH
Limit Humidity Alarm Offset 5.0%RH
BMS Timeout 10 sec
BMS Address 1
BMS Baud rate 19,200
BMS Protocol Select BACnet
Control Humidity Sensor Type 4-20mA
Control Humidity Set Point 45.0%RH
Control Humidity Cut-in -4%RH
Control Humidity Cutout 0.0%RH
Limit Humidity Sensor Type 4-20mA
Control Temperature Sensor Type 4-20mA
Parameter Set Point
High Control Humidity Alarm 70.0%RH
Low Control Humidity Alarm 30% RH
Control Humidity Alarm Offset 5.0%RH
Drain Duration 10 mins.
Cabinet Temperature Sensor X minimum 0.0
Cabinet Temperature Sensor X minimum 100.0
Cabinet Temperature Sensor Y minimum 0.0°C
Cabinet Temperature Sensor Y minimum 100.0°C
NTC2 Temperature Sensor X minimum 0.0
NTC2 Temperature Sensor X minimum 100.0
NTC2 Temperature Sensor Y minimum 0.0°C
NTC2 Temperature Sensor Y minimum 100.0°C
NTC3 Temperature Sensor X minimum 0.0
NTC3 Temperature Sensor X minimum 100.0
NTC3 Temperature Sensor Y minimum 0.0°C
NTC3 Temperature Sensor Y minimum 100.0°C
NTC4 Temperature Sensor X minimum 0.0
NTC4 Temperature Sensor X minimum 100.0
NTC4 Temperature Sensor Y minimum 0.0°C
NTC4 Temperature Sensor Y minimum 100.0°C
Group Rotation Hours 24 hours
Humidifier Type 3
Limit Temperature Sensor Type 4-20mA
Conductivity Delay 10 sec
Group A Restrictor 100%
Group Switch Time 24 hours
Group B Restrictor 100%
Limit Humidity Cut-in -4.0%rH
Limit Humidity Cutout 0.0%RH
Limit Temperature Cut-in -4.0°F
Limit Temperature Cutout 0.0°F
Group B Assist Rotate
Humidifier Modbus number of stop bits 0
Humidifier Modbus parity None
Humidifier Modbus Baud rate 19,200
Operating Mode
2
(See Table,
Section 5.7.1)
Clock Adjust 3600
Drain hours high 0
Drain hours low part 72 hours
High Control Temperature Alarm Enable No
Low Control Temperature Alarm Enable No
High Control Humidity Alarm Enable Yes
Low Control Humidity Alarm Enable Yes
Fahrenheit is Temperature Unit of Measure Yes
Auto Reset Yes
Auto Reset Remote Yes
Smoke Shutdown on Alarm No
Drain Enable Yes
Suppress Buzzer Yes
High Limit Temperature Alarm Enable No
Air Speed Units fpm
Low Limit Temperature Alarm Enable No
Freeze Alarm Enable No
