STULZ Ultra-Series Humidifier Controller
38 (August, 2013)
Humid Frz Alarm No
Humid Hi T Alarm No
Humid Low W Alarm No
Humid Fill Alarm No
Humid Comm Alarm No
Humid Xducer Alarm No
Humid Volt Alarm No
High Airflow Alarm No
Low Airflow Alarm No
Options
DigitalIn
Run Hours
111111111
123456789012345678
pco: CCCCCCCCCC00000000
DigitalIn
RUN HOURS
BMS Comm
Humidifier 0018hrs
Starts 1
Reset Off
NOTE
The selections in the above screen are the alarms
from the humidifiers.
NOTE
The above screen is shown only a large E-Ultra
Controller.
As an example, for a custom alarm based only on the
occurrence of high humidity, water detection, smoke and
high water conductivity scroll through the screens and
enter "Yes" in the appropriate fields as shown. Upon
detection of any of the selected alarm conditions, the
alarm key illuminates and the controller energizes the
designated custom alarm relay.
Digital In 5.5.5
This screen is provided for information only. It shows the
state of each digital input as either Closed or Open. Only
the first 10 inputs are used on the E-Ultra controller to
date. The rest are shown as zeros.
Run Hours 5.5.6
The run hours display screen shows the number of hours
the humidifiers have been running at 10% or greater
output. Also shown is number of starts logged for the
humidifier (transition from below to above 10% output. The
run hours and starts values may be reset to 0 from this
display screen. The values displayed are the values
logged since the last time the screen was reset.
Custom Alarm 1 Product
Custom Alarm 1 Product
SERVICE MENU software
Digital Inputs is needed.
SERVICE MENU software
Starts/Run Hours Product
