STULZ Ultra-Series Humidifier Controller
56 (August, 2013)
Modbus
TCP/IP
BMS
Address
Modbus
Address
BACnet
Address Description Default
Read/
Write
013 12 013 12 Customer alarm input 2 R/W
014 13 014 13 Customer alarm input 3 R/W
015 14 015 14 Custom Alarm 1 R
016 15 016 15 Custom Alarm 2 R
017 16 017 16 Custom Alarm 3 R
018 17 018 17 Custom Alarm 4 R
019 18 019 18 Cabinet Fan R
020 19 020 19 High control temperature alarm R
021 20 021 20 Low control temperature alarm R
022 21 022 21 High control humidity alarm R
023 22 023 22 Low control humidity alarm R
024 23 024 23 Cabinet high temperature alarm R
025 24 025 24 Cabinet low temperature alarm R
026 25 026 25 NTC2 high temperature alarm R
027 26 027 26 NTC2 low temperature alarm R
028 27 028 27 NTC3 high temperature alarm R
029 28 029 28 NTC3 low temperature alarm R
030 29 030 29 NTC4 high temperature alarm R
031 30 031 30 NTC4 low temperature alarm R
032 31 032 31 Control temperature sensor fail R
033 32 033 32 Control humidity sensor fail R
034 33 034 33 Limit temperature sensor fail R
035 34 035 34 Limit humidity sensor fail R
036 35 036 35 Conductivity sensor fail R
037 36 037 36 Airspeed sensor fail R
038 37 038 37 Conductivity Pre-Alarm R
039 38 039 38 Conductivity Alarm R
040 39 040 39 High Control Temperature Alarm Enable R
041 40 041 40 Low Control Temperature Alarm Enable R
042 41 042 41 High Return Humidity Alarm Enable R
043 42 043 42 Low Return Humidity Alarm Enable R
044 43 044 43 High Airflow Alarm R
045 44 045 44 Low Airflow Alarm R
046 45 046 45 High limit temperature alarm R
047 46 047 46 Low limit temperature alarm R
048 47 048 47 Enable high limit temperature alarm R/W
049 48 049 48 Enable low limit temperature alarm R/W
050 49 050 49 High limit humidity alarm R
051 50 051 50 Enable high humidity alarm R/W
052 51 052 51 Enable low humidity alarm R/W
053 53 053 52 Low limit humidity alarm R
057 56 057 56 Airflow Shut Down Enable R/W
058 57 058 57 Airflow Shut down R
059 58 059 58 BMS Freeze Alarm Enable R/W
060 59 060 59 Freeze alarm R
102 101 102 101 Remote shutdown R/W
103 102 103 102 --- ---
104 103 104 103 Group Select R/W
105 104 105 104 Reset Alarms R/W
106 105 106 105 Group Select Enable R/W
10.4 Alarm Packed Bit Variables
Bit
V
alue Alarms 1
A
larms 2 Humidifier x
A
larms
0 1 High control temperature alarm Control temperature sensor fail Low water alarm
1 2 Low control temperature alarm Control humidity sensor fail Fill failure alarm
