to OFF, OFF to ON, or the vehicle starts
moving before the setting procedure is
finished.
. Setting the speed is impossible
when the vehicle is moving.
. The set engine speed may differ
from the engine speed shown by the
tachometer. Use the engine speed
shown by the tachometer as a rough
guide.
. If the setting operation is performed
with the engine switch turned off, the
REV indicator light turns off and the
setting operation is aborted when you
have stopped the setting operation for
approximately 10 seconds.
. If the setting operation is performed
with the engine switch turned off, the
REV indicator light turns off and the
setting operation is aborted when you
open and close the driver’s door.
& Deactivating the REV alarm
system
To deactivate the REV indicator light and
buzzer functions of the REV alarm system,
set the thousands place of the alarm-level
engine speed to “–”.
Warning and indicator lights
Several of the warning and indicator lights
illuminate momentarily and then turn off
when the ignition switch is initially turned
to the “ON” position. This permits check-
ing the operation of the bulbs.
Apply the parking brake and turn the
ignition switch to the “ON” position. The
following lights illuminate:
: Seatbelt warning light
(The seatbelt warning light turns off
only when the dri ver fastens the
seatbelt.)
: Front passenger’s seatbelt warning
light
(The seatbelt warning light turns off
only when the front seat passenger
fastens the seatbelt.)
: SRS airbag system warning light
ON /
: Front passenger’s frontal airbag
ON indicator light
/ : Front passenger’s frontal airbag
OFF indicator light
: CHECK ENGINE warning light/Mal-
function indicator lamp
: Coolant temperature high warning light
(non-turbo models)
: Charge warning light
: Oil pressure warning light
: AT OIL TEMP warning light
(AT models)
: Rear differential oil temperature warn-
ing light (STI)
: Low tire pressure warning light
(U.S.- spec. models)
/ : ABS warning light
/ : Brake system warning light
: Low fuel warning light
: Hill start assist warning light (MT
models – if equipped)/Hill start assist
OFF indicator light (STI)
: Door open warning light
: AWD warning light (AT models)
: Vehicle Dynamics Control operation
indicator light
: Vehicle Dynamics Control warning
light/Vehicle Dynamics Control OFF
indicator light/Traction Control OFF
indicator light (STI)
: SPORT mode indicator light
(AT models)
Instruments and controls 3-13
– CONTINUED –
