& Warning and indicator lights
Mark Name Page
Seatbelt warning light 3-9
Front passenger’s
seatbelt warning light
3-9
SRS airbag system
warning light
3-11
/
Front passenger’s
frontal airbag ON indi-
cator
3-11
/
Front passenger’s
frontal airbag OFF in-
dicator
3-11
CHECK ENGINE
warning light/Malfunc-
tion indicator light
3-12
Coolant temperature
low indicator light/
Coolant temperature
high warning light
3-13
Charge warning light 3-14
Oil pressure warning
light
3-14
Engine oil level warn-
ing light
3-14
Mark Name Page
AT OIL TEMP warning
light (CVT models)
3-15
ABS warning light 3-16
Brake system warning
light
3-17
Door open warning
light
3-19
AWD warning light
(AWD CVT models)
3-19
Power steering warn-
ing light
3-19
Hill start assist warn-
ing light (MT models)/
Hill start assist OFF
indicator light (MT
models)
3-18
Vehicle Dynamics
Control warning light/
Vehicle Dynamics
Control operation indi-
cator light
3-20
Vehicle Dynamics
Control OFF indicator
light
3-21
Turn signal indicator
lights
3-22
Mark Name Page
High beam indicator
light
3-23
Automatic headlight
beam leveler warning
light (if equipped)
3-23
Front fog light indicator
light (if equipped)
3-23
Security indicator light 3-21
Headlight indicator
light (if equipped)
3-23
Cruise control indica-
tor light
3-23
Cruise control set in-
dicator light
3-23
Low fuel warning light 3-18
Low tire pressure
warning light
(U.S.-spec. models)
3-15
Shift-up indicator light
(MT models)
3-22
