11-6 Maintenance and service
Engine compartment overview
1) Brake fluid reservoir/Clutch fluid reservoir
(MT) (page 11-15)
2) Fuse box (page 11-35)
3) Battery (page 11-34)
4) Windshield washer tank (page 11-28)
5) Engine oil filler cap (page 11-7)
6) Engine coolant reservoir (page 11-11)
7) Radiator cap (page 11-11)
8) Engine oil level gauge (page 11-7)
9) Air cleaner case (page 11-12)
