11-44 Maintenance and service
the lens with a flat-head screwdriver.
2. Pull the bulb out of the socket.
3. Install a new bulb.
4. Reinstall the lens.
& Trunk light
1. Remove the cover by squeezing its
sides and pulling it.
2. Pull the bulb out of the socket.
3. Install a new bulb.
4. Reinstall the cover.
& High-mounted stop light
(4-door)
1) Trunk light
1. Open the trunk and locate the elec-
trical connector of the high-mounted stop
light that is wired near the trunk light by
referring to the illustration.
2. Disconnect the electrical connector by
unlocking its retainer using a flat-head
screwdriver. Then, enter the rear cabin.
1) Mount assembly
3. While pushing the mount assembly
rearward by hand, lift up the front end of
the mount assembly to remove it. At this
time, be careful not to allow your hand to
slip off the mount assembly.
