Instruments and controls/Multi function display
& Interruption screen
Warning information (display example)
Useful messages, such as reminder in-
formation, vehi cle i nformation, warning
information, etc. may interrupt the current
screen and appear on the display accom-
panied by a beep. Take proper action
according to the message.
The warning screen will return to the
original screen after a few seconds. If
the warning screen can be displayed
again, an information reminder “
” will
appear on th e uppe r left p art of the
display. To recall the message marked
with “
” on the display, pull the “ /SET”
switch on the steering wheel toward you.
& Basic screens
These are the basic screens of the multi
function display.
Item Page
Information bar 3-40
Fuel consumption screen 3-42
ECO gauge screen 3-42
ECO history screen 3-42
Vehicle activation status
screen
3-43
EyeSight screen (models with
the EyeSight system)
3-44
Triple meter screen 3-44
“Boost pressure” and “Accel-
erator opening ratio” screen
(turbo models)
3-46
Guidance screen 3-45
Clock/calendar screen
3-45
By operating the “ ” or “ ” switch on the
steering wheel, you can switch the screen
that is always displayed. Also, when the
“
/SET” switch is pulled and held, the
selection screen can be displayed. For
details about the selection screen, refer to
“Selection screen” F3-47.
! Information bar
1) Information bar
2) Outside temperature indicator
3) Information reminder
4) Top display
5) Clock
While the ignition switch is in the “ACC” or
“ON” position, the outside temperature
indicator, clock, etc. will be shown on the
information bar.
! Outside temperature indicator
This displays the outside temperature
between − 408F(− 40 8C) and 1228F
(508C).
3-40
