Sukup Sweepway - Page 64

Parts/Assemblies
64
20° INCLINE AUGER FOR 10” UNLOAD
(E5010 – 3-belt)
REF. #
DESCRIPTION
QTY.
PART #
1
Transition
1
E5011
2
Tube
1
E5012
3
Bearing
2
E5013
4
Bearing support
2
E5014
5
Intermediate shaft
1
E5016
6
Auger shaft
1
E5017
7
Transition cover
1
E5019
8
Front plate
1
E5022
9
Brace
2
E5023
10
Motor mount brace
1
E5024
11
Unload shaft
1
E54143
12
Flighting, 5’
1
E56233
13
Support shaft
1
E56241
14
Pivot rod
1
E57441
15
Base plate spacer
1
E5768-03
16
Shield, inner
1
E5972
17
Shield, outer
1
E5973
18
Shield bracket
2
E5975
19
U-joint
2
E5985
20
Motor, mount
1
E5992
21
Half band
1
EE412
22
Flighting, 11” OD, 5”
1
EU1185
23
Key, 3/8”, 1-5/8”
4
G5316
24
Flange bearing, 2”, 4-bolt
1
J00493
25
Screw, 5/16 – 18 x 1”
8
J0527
26
Screw, 3/8 – 16 x 1”
32
J0611
27
Screw, 3/8 - 16 x 3”
2
J0660
28
Screw, 7/16 – 14 x 1-1/4”
4
J0722
29
Screw, 1/2 – 13 x 1-1/2”
4
J0730
30
Screw, 1/2 – 13 x 3”
4
J0750
31
Screw, 1/2 – 13 x 3-1/2”
5
J0754
32
Screw, 5/8 – 11 x 2”
4
J0791
33
Screw, 3/4 - 10 x 6”
1
J0824
34
Flange lock nut, 3/8” - 16
34
J1017
35
Lock nut, 7/16" – 14
4
J1034
36
Lock nut, 1/2" – 13
13
J1042
37
Nut, 5/8" – 11
4
J1046
38
Nut, 3/4" – 10
1
J1051
39
Flat washer, 5/16”
8
J1111
40
Flat washer, 3/8”
2
J1117
41
Flat washer, 1/2"
2
J1125
42
Split lock washer, 5/16”
8
J1200
43
Split lock washer, 5/8”
4
J1218
44
Machine bushing, 3/4 x 1-1/4”, 14ga
5
J1260
45
Bushing, rubber, 1/2" ID
4
J5021
46
Hairpin clip, .120 x 2.5
2
J5412
47
Decal, Do Not Enter Bin, Keep Clear of Augers
1
L0258A
48
Decal, Danger, Replace Missing Shield
2
L0271
49
Decal, Safe Operation
2
L0281
50
Decal, Keep Away From Moving Parts
2
L0284
51
Sukup logo
2
L03161
