2-1
CHAPTER
2
Disk Drive, Air Management Sled,
and Tabletop Cover FRUs
This chapter provides instructions for removing and installing a disk drive, air
management sled, and tabletop cover FRUs, and covers the following topics:
■ “Replacing a Disk Drive” on page 2-2
■ “Identifying the Defective Disk Drive” on page 2-3
■ “Removing a Defective Disk Drive” on page 2-4
■ “Installing a New Disk Drive” on page 2-5
■ “Scanning the New Drive and Related Procedures” on page 2-6
“Scanning the New Drive” on page 2-6
“Checking and Performing the Correct Powerup Sequence” on page 2-7
“Assigning a Disk Drive as a Spare” on page 2-8
“If the Logical Drive Status is REBUILDING” on page 2-9
“Automatic Rebuild and Automatic Global Spare Assignments After a
Failed Drive is Replaced” on page 2-9
■ “Installing an Air Management Sled” on page 2-11
■ “Adding or Removing the Tabletop Cover” on page 2-11
■ “Converting a Rack-Ready Array to a Tabletop Array” on page 2-12
■ “Converting a Tabletop Array to a Rack-Ready Array” on page 2-14
