ioxadm(8)
System Administration 87
In EXAMPLE 3, the list command is used to display the connections between
External I/O Expansion Units and downlink cards in the host. IOX@0033 (which
includes boats, uplink cards, and power supplies) is connected to the host through
two downlink cards. The Link 0 column shows which host downlink card is
attached to boat0. The Link 1 column shows which host downlink card is
attached to boat1. IOX@12B4 is connected to the host through one downlink card.
This card is connected to boat1.A"–" shows that there is no host link connection
to the box. It may have a boat and uplink card installed in the bay, or the bay could
be empty. If the boat is installed, either it is not connected to the host, or the host
downlink card slot is powered off.
EXAMPLE 4 Displaying a Single External I/O Expansion Unit
EXAMPLE 5 Displaying a Single External I/O Expansion Unit Using Verbose Output
EXAMPLE 6 Displaying a Downlink Card Using Hostpath in Verbose Mode With Headers
Suppressed
EXAMPLE 7 Powering On the Locator LED for Power Supply 0 in External I/O Expansion
Unit 12B4
XSCF> ioxadm list iox@12B4
IOX Link 0 Link 1
IOX@12B4 - IOU#1-PCI#2
XSCF> ioxadm -v list IOU#1-PCI#1
Location Type FW Ver Serial Num Part Num State
IOX@X07A IOX 2.1 XCX07A CF005016937/5016937-03 On
IOX@X07A/PS0 A195 - DD0579 CF003001701/3001701-04 On
IOX@X07A/PS1 A195 - DD0588 CF003001701/3001701-04 On
IOX@X07A/IOB0 PCIE - XE00E5 CF005016939/5016939-05 On
IOX@X07A/IOB0/LINK CU 2.0 XF01HJ CF005017040/5017040-04 On
IOU#0-PCI#3 CU 2.0 XF01AD CF005017040/5017040-03 On
XSCF> ioxadm -p -v list IOU#0-PCI#2
IOU#0-PCI#2 OP 2.0 XF01A1 CF005017040/5017040-03 on
XSCF> ioxadm locator on iox@12B4/ps0
