- 03 -
2.3 Install the TF Card
Illuminati camera comes with a built-in micro SD card slot that can store
videos and snapshots.
1
Remove the 4 screws to take
off the camera back cover.
Insert the TF card as directed
by the arrow.
2
2.2 PoE+ Requirement
PoE+IEEE 802.3at standard is required. Note traditional PoE system( 802.
3af standard) delivers up to 15.4W, which is unable to fully support the
camera. Dome cameras, especially with 20x zoom-in capacity, have
higher power requirements than fixed cameras.
Transmission distance
PoE will also drop power along the Ethernet cable. With PoE+ adapter supplying
30W, please don’t run Ethernet over 200ft. The maximum travel distance depends
on the quality of the cable and the maximum power supplied by switch/injector.
NVR’s built-in PoE switch
Some NVRs have built-in PoE switches. It is important to check whether each port
can supply at least 25W (with 802.3at) as some of those are for bullet cameras and
can’t supply enough power for PTZ (with 802.3af only).
Biggest issue when underpower
In the daytime, even 802.3af (conventional PoE system) can provide enough power
to the camera. However, in the night time, if you are underpower, the following
problem begins: low light environment detected -> infrared on -> not enough power
-> reboot -> low light environment detected -> infrared on -> not enough power ->
reboot …… (cycling)
