15
Utility knife Marker Rubber mallet Measuring tape
Level Hammer drill (φ10) Phillips screwdriver
(M4,M5,M6)
Wrench (16mm、
17mm、35mm)
Hydraulic plier Heat gun Allen wrench (M5) MC4 Wrench
Tube terminal
crimping tool
Wire stripper MC4 terminal crimp-
ing tool(4–6 mm
2
)
4.6 PE Cable Preparation
Additional grounding cable is prepared by customers.
table 4-2 Cable requirements
Type Specification
Complying with 1000V and 105℃ standard
4–6 mm
2
step 1 Prepare the cable and OT/DT terminal.
User Manual 4 Mounting
