Sungrow SBR096 User Manual

47
Parameters SBR096 SBR128 SBR160
Over current
protection
Yes
Over / under
temperature
protection
Yes
DC breaker Yes
General Data
Dimensions
(W*H*D)
625 * 545 * 330
mm
625 * 675 * 330
mm
625 * 805 * 330
mm
Weight 114 kg 147 kg 180 kg
Installation
location
Indoor / Outdoor
Mounting
method
Floor stand
Operating
temperature
Charge: 0 to 50℃
Discharge: -20 to 50℃
Degree of
protection
IP55
Allowable rela-
tive humidity
range
0% to 95% no condensing
Max. operating
altitude
Max. 2000 m
Cooling
method
Natural convection
Warranty
2
10 Years
Expansion
adaptation
Up to 4 units in parallel（need extra Combiner box）
1: Test conditions: 25℃,100% depth of discharge (DOD), 0.2C charge and discharge
2: Refer to battery warranty card for conditional application.
table 9-2 Technical parameters of high voltage LFP battery(SBR192 / SBR224 / SBR256).
Parameters SBR192 SBR224 SBR256
System Data
Battery Type
LiFePO4 Prismatic Cell
Battery Module 3.2 kWh, 33 kg
Energy (usable)
1
19.2 kWh 22.4 kWh 25.6 kWh
Nominal voltage
384 V 448 V 512 V
Operating voltage
300 V – 438 V 350 V – 511 V 400 V – 584 V
Rated DC power
11.52 kW 13.44 kW 15.36 kW
Max. charge/dis-
charge power
13.14 kW 15.33 kW 17.52 kW
User Manual 9 Appendix
