Sungrow SC5000UD-MV-US System Manual

117
Parameter SC2400UD-MV-US SC2750UD-MV-US
AC voltage distortion < 3 % (Linear load)
DC voltage component < 0.5 % Un (Linear balance load)
Unbalance load capacity
100 %
Nominal voltage frequency /
Voltage frequency range
60 Hz / 55 – 65 Hz
Efficiency
Converter Max. efficiency
99 %
Converter CEC efficiency
98.5%
Transformer rated power
2400 kVA 2750 kVA
Transformer max. power
2400 kVA 2750 kVA
LV / MV voltage 0.48kV/[12.47–34.5]kV
0.55kV/[12.47–34.5]kV
Transformer vector
Dy11
Transformer cooling type ONAN (Optional:KNAN)
Oil type Mineral oil(PCB free) or degradable oil on request
Protection
DC input protection
Load break switch + fuse
Converter output protection
Circuit breaker
AC output protection
Load break switch + fuse
Surge protection DC Type II / AC Type II
Grid monitoring / Ground
fault monitoring
Yes / Yes
Insulation monitoring
Yes
Overheat protection
Yes
General data
Weight 16000kg（35274lbs.）
Degree of protection
TYPE 3R
Operating ambient temper-
ature range
-35 to 60℃(> 45 ℃ derating)/'-31 to 140 ℉ (> 113 ℉
derating)
Allowable relative humidity
range
0 - 100 %
Max. operating altitude 1000 m (Standard) / > 1000 m (Optional)
