Sungrow SC5000UD-MV-US System Manual

79
Parameter
Desciptions
Default
Range
fpwrdec Over-frequency derating start point on
P(f) curve
60.1 45Hz-65Hz
fpwrinc Under-frequency rising start point on P
(f) curve
59.9 45Hz-65Hz
PdecGrad Power derating gradient on P(f) curve 100% Pn/Hz 0~200%Pn/
Hz
PIncGrad Power rising gradient on P(f) curve 100% Pn/Hz 0~200%Pn/
Hz
PdecMax Maximum derating power on P(f) curve 100% 0%~110%
PIncMax Maximum rising power on P(f) curve 100% 0%~110%
P-U Curve
figure 10-2 P(U) curve
table 10-2 Description of P-U curve Parameters
Parameter
Desciptions
Default
Range
PU
Characteristics
Enable/Disable P-U curve 0 0-1
PU Voltage In-
crease Start
Point
Over-voltage derating start point on P-
U curve - Discharge
106.0% Un 100%~110%
PU Voltage In-
crease End
Point
Over-voltage derating end point on P-
U curve - Discharge
110.0% Un 100%
~120%
System Manual 10 PCS Functions
