20
NNoo..
SSppeecciiffiiccaattiioonn
e
Opening:13mm, 16mm
f
Crimp range 4~6mm
2
g
Range≥1100Vdc
h 15mm
4.4 Moving the Inverter
Move the inverter to the specified position before installation. The inverter can be moved
manually or via a hoist.
4.4.1 Manual Transport
Lift and move the inverter to the destination by using the side handles and bottom
handles.
Inappropriate moving operation may cause personal injury！
• It is recommended that at least two installers carry the inverter together and
wear protective equipment such as smash-proof shoes and gloves
• Always beware of the gravity center of the inverter and avoid tipping.
The ground surface on which the inverter is to be placed should be covered with
a sponge pad, foam cushion or the like to prevent the inverter bottom from
getting scratched or other damages.
4 Mechanical Mounting User Manual
