Sungrow SG8K3-D - Setting Protective Parameters

7 LCD Operation User Manual
48
7.5.2 Setting Protective Parameters
Protective parameters are designed for the threshold values that can trigger the
protective function of the inverter. The threshold values are compliant with the
requirements of local safety standards and the utility grid.
If the protection function is triggered, the inverter will automatically disconnect
from the grid with the ”Error xxx” state displayed on the LCD main screen. After
the grid voltage or frequency recovers to the specified range, the inverter will
start running normally and can reconnect to the grid.
Touch ESC to choose the item and press ENT to enter the setting interface.
Volt-watt
Single/Mul Prot.
Prot. Recover
Grid Prot. Adj.
10 Min Over Vtg En.
* The settings for “10 Min Over Vtg En”. and “Volt-watt” are invalid for the
country code “BRA”.
Single/Multiple Protection
Touch ESC to change the value and touch ENT to move the cursor.
Confirm settings by pressing ENT.
Confirm settings and scroll pages by pressing ENT.
2-Vmax: 242.0V
2-
Vmin: 176.0V
1-Vmax: 242.0
V
1-Vmin: 176.0V
Multi
. stage
Single
stage
Vmin: 176.0V
Vmax: 242.0V
Tab. 7-3 Protective Parameters Explanation and the Range
Parameter Explanation Range (V)
V
max
Grid over-voltage
230.0–277.0
V
min
Grid under-voltage
176.0–230.0
1-V
max
Grid over-voltage 1 (V>)
230.0–277.0
2-V
max
Grid over-voltage 2 (V>>)
230.0–277.0
1-V
min
Grid under-voltage 1 (V<)
176.0–230.0
2-V
min
Grid under–voltage 2 (V<<)
176.0–230.0
Tab. 7-4 Default Protective Parameters
Parameter
Default Value for “BRA”
Default Value for “MX”
220 V
230 V
240 V
220 V
230 V
240 V
V
max
(V)
242.0
253.0
264.0
231.0
241.5
252.0
V
min
(V)
176.0
184.0
192.0
209.0
218.5
228.0
1-V
max
(V)
242.0
253.0
264.0
231.0
241.5
252.0
