47
2) How to Attach the Needle
3) How to Hook the Upper Thread
After unfastening the needle fixing screw on the needle
bar, have the long groove of the needle face the back
and push the needle till it touches the needle insertion
hole and then tighten the needle fixing screw.
After placing the thread take-up at the highest position, hook the thread as shown in the picture below.
[ Fig. 70 ]
[ Fig. 71 ]
4) How to Hook the Lower Thread
A. Insert bobbin 󳟆 into bobbin case 󳟇 as shown in the
picture.
B. Place the lower thread through the crack in the
bobbin case.
[ Caution ]
For type SPS/B(A)-1306(1507)-HP(GP)-󳣑 󳣑 the needle is
inserted in the opposite directions of other machine types.
[ Caution ]
The bobbin must turn clockwise when seen from the
back of the bobbin case.
Screw
Needle
[ Fig. 72 ]
󳟇
󳟆
