SUNSTONE CD200DP-A - Page 39

39
TABLE 3: Sunstone Dual Pulse General Technical Specications
Feature All CDDP-A Welders
Single and Dual Pulse Yes
Pulse 1 Energy Adjustment (%of set-point energy) 0% - 30%
Pulse 2 Energy Adjustment (%of set-point energy) 0% - 100%
TABLE 4: Power Specications
CD200DP-A CD400DP-A CD600DP-A
Input Voltage 85 - 260 VAC 85 - 260 VAC 85 - 260 VAC
Frequency Range 47-63Hz 47-63Hz 47-63Hz
Power Factor (typ.)
PF>0.94/230VAC
PF>0.99/115VAC
PF>0.94/230VAC
PF>0.99/115VAC
PF>0.94/230VAC
PF>0.99/115VAC
AC Current (typ.)
8.5A/115VAC
5A/230VAC
8.5A/115VAC
5A/230VAC
8.5A/115VAC
5A/230VAC
TABLE 5: Weld Pulse Characteristics
Model
Min and Max
Output
Pulse Width
Rise Time
(to max voltage)
Min Pulse Height
Max Pulse
Height
CD200DP-A 0.2 ws - 200 ws
Min 0.27 ms
0.2 ms 1.1 V 15.8 V
Max 19.5 ms
CD400DP-A 0.2 ws - 400 ws
Min 0.29 ms
0.2 ms 0.9 V 18.3 V
Max 30.0 ms
CD600DP-A 0.2 ws - 600 ws
Min 0.31 ms
0.2 ms 0.8 V 19.4 V
Max 40.5 ms
TABLE 6: Welder Physical Characteristics
CD200DP-A CD400DP-A CD600DP-A
Inches cm Inches cm Inches cm
Height 12 30.5 12 30.5 12 30.5
Width 9 22.8 9 22.8 9 22.8
Depth 19 48.2 19 48.2 19 48.2
Weight 43.3 Lbs 19.6 Kg 44.5 Lbs 20.2 Kg 45.8 Lbs 20.8 Kg
