Page | 27
SUNSYNK MAX | User Manual
4.14.3. PV Protection
3. Insert the contact pin into the connector housing
until it locks into place. Then screw the cap nut
onto the connector housing. Torque to 2.5-3 N.m
4. Finally, insert the DC connector into the positive
and negative input of the inverter.
2. Crimp metal terminals with crimping pliers.
