SunSynk SYNK-8K-SG04LP3 User Manual

THREE PHASE HI 8~12kW | Installer Manual11
TECHNICAL SPECIFICATIONS
Model SYNK-8K-SG04LP3 SYNK-10K-SG04LP3 SYNK-12K-SG04LP3
Battery Input Date
Battery Type Lead-acid or Li-Ion
Battery Voltage Range 40Vd.c ~ 60Vd.c
Max. Charging/Discharging
Current
190Ad.c (max.) 210Ad.c (max.) 240Ad.c (max.)
Charging Curve 3 Stages / Equalization
External Temperature Sensor Yes
Charging Strategy for Li-Ion
Battery
Self-adaption to BMS
PV String Input Data
Max. DC Input Power 10400W 13000W 15600W
PV Input Voltage 550Vd.c (160Vd.c ~ 800Vd.c)
MPPT Range 200Vd.c ~ 650Vd.c
Start-up Voltage 160V
PV Input Current 13Ad.c + 13Ad.c 26Ad.c + 13Ad.c
Max. PV Isc 17Ad.c + 17Ad.c 34Ad.c + 17Ad.c
No. of MPPT Trackers 2
No. of Strings Per MPPT Tracker 1+1 2+1
AC Output Data
Rated AC Output and UPS Power 8000W 10000W 12000W
Max. AC Output Power 8800W 11000W 13200W
Peak Power(o grid) 2 times of rated power, 10s
AC Output Rated Current 12.1/11.6A 15.2/14.5A 18.2/17.4A
Max. AC Current 13.4/12.8A 16.7/15.9A 20/19.1A
Max. Three-phase Unbalanced
Output Current
18.2/17.4A 22.7/21.7A 27.3/26.1A
Max. Output Short Circuit Current 75A
Max. Continuous AC Passthrough 45A
Output Frequency and Voltage 50/60Hz;3L/N/PE 220/380, 230/400Vac (Three phase)
Grid Type Three phase
Total Harmonic Distortion (THD) <3% (of nominal power)
DC current injection <0.5% ln
Eciency
Max. Eciency 97.60%
Euro Eciency 97.00%
MPPT Eciency >99%
Protection
Integrated
PV Arc Fault Detection, PV Input Lightning Protection,
Anti-islanding Protection, PV String Input Reverse Polarity Protection,
Insulation Resistor Detection, Residual Current Monitoring Unit,
Output Over Current Protection, Output Shorted Protection
Surge Protection DC Type III / AC Type III
Over Voltage Category DC Type II / AC Type III
