SUNWARD SWE90F-1 - Swe80 F-1 Machine Specification; Machine Specification

168
6. 8SWE80F-1 Machine specification
6.8.1 Machine specification
Machine specification
SWE80F-1
Operation weight
8000 kg
Standard bucket capacity
0.26m3
Track shoe width
450 mm
Power plant
Engine model
4TNV98C-SSU
Type
Direct injection, water cooled, 4
strokes
Bore ｘstoke
4
Displacement
3.319 L
Rated power/revs
46.2kW/2200rpm
Fuel tank capacity
145 L
Hydraulic system
Main pump
1 variable plunger pump
Flow capacity
167L/min
Work pressure setting
30 MPa
Front work
equipment(force increase state)
28 Mpa
Travel
28 Mpa
Slewing
23Mpa
pilot pressure setting
3.5 Mpa
Hydraulic oil tank capacity
90 L
Performance specification
Slewing speed
11 rpm
Travel speed
4.7/2.8 km/h
Max traction
73 kN
Max grade ability
35°
Bucket max digging force
55.3 kN
Arm max digging force
34 kN
