2.12 WIND HOOD AND UPPER-COVER
Wind hood:
The engine should be equipped with air ducting hood to prevent foreign materials
from being reeled into fan which disturbs the normal work of fan. On the other hand,
the assembly of air ducting hood can prevent accident caused by carelessly putting
hand into the fan (As figure 2.12). It is equipped with mounting plate on both left
and right and is connected with the water tank.
Upper-cover
The upper-cover can protect the hydraulic components, electric circuit in the interior of the excavator and
ensures the beautiful appearance. It is fixed on the platform and also protects engine. Upper-cover can be
opened at the rear position of the machine, its convenient for daily maintenant and exam.
2.13 LABELS
Gravity center label： Traction hook label：
