SUNWARD SWE90F-1 - Configuration Specification

169
6.8.2 Configuration specification
Machine specification
SWE80F-1
A、
Tumbler distance
2269
B、
Overall length of crawler
2897
C、
Platform ground clearanece
805
D、
Tail swing radius
1790
E、
Chassis width
2260
F、
Crawler width
450
G、
Chassis ground clearance
570
H、
Crawler height
675
I、
Overall length
6220
J、
Overall height of cab
2645
Unit：mm
