SUNWARD SWL2820 - Overall Dimension

SWL2820 Operator’s Manual
26
3.2.2 OVERALL DIMENSION
Item Specification SWL2820
A Overall operating height
3850 ㎜
B Height to bucket hinge pin
3002 ㎜
C Height to top of cab
2018 ㎜
D Height to bottom of level bucket
2834 ㎜
E Overall length without attachment
2475 ㎜
F Overall length with standard bucket
3261 ㎜
G Dump angle at maximum height 42°
H Dump height
2320 ㎜
J Reach at maximum height
475 ㎜
