SWL2820 Operator’s Manual
47
BUCKET OPEN
4.8 LOADING
4.8.1 LOADING ON LEVEL FLOOR
1) Start moving with the arm completely
lowered and directs the bucket forward
the base of the material what you want to
load.
2) Move forward to the material, while the
bucket is full, gradually raise the boom and fold the bucket until the end of
stroke at the same time. Slow down the
moving speed till stop during loading.
3) Move reverse and dump the material to
where you desire.
4.8.2 LOADING ON SLOPES
 While doing the loading on slopes, the regulations
of MOVING ON SLOPES must be followed with.
 Only do the loading on slopes when it is
absolutely necessary.
 Always go up with the bucket directly forward
and go down in reverse with the bucket forward and lowered.
 Never go down from higher place to load material downwards. It extremely easy to
cause machine overturn.
 Always keep the bucket lowered as much as
possible.
1) Start moving with the arm completely
lowered and directs the bucket forward
the base of the material what you want to
load.
2) Move forward to the material, while the
bucket is full, gradually raise the boom and fold the bucket until the end of
stroke at the same time. Slow down the moving speed till stop during loading.
