SWL2820 Operator’s Manual
60
Engine oil 7.4
Fuel tank 70
Travelling Mechanism 2X15
5.3.3 CODIFICATION OF THE MAIN CHANGED PART
The following table shows the codification of the parts need changing frequently.
SWL2820
PART MANUFACTURER CODE
Engine Air Filter Yanmar 750201000020
Engine Oil Filter Yanmar 750201000020
Engine Fuel Filter Yanmar 750201000020
Hydraulic Oil Filter Internorman 730401000076
5.3.4 TORQUE FOR SCREWS
Unless other specification, tighten the nuts and bolts according to the torques shown in the
below table. Tighten the goods by the wrenches with gauge.
Thread Diameter (mm) Quality 8.8 Torque (Nm) Quality 10.9 Torque (Nm)
M 6 9~12 13~16
M 8 22~30 30~36
M 10 45~59 65~78
M 12 78~104 110~130
M 14 124~165 180~210
M 16 193~257 280~330
M 18 264~354 380~450
M 20 376~502 540~650
M 22 512~683 740~880
M 24 651~868 940~1120
M 27 952~1269 1400~1650
M 30 1293~1723 1700~2000
When tighten parts of the machine made by steel be careful to not tighten it too strong,
since you could damage this parts.
