SWL2820 Operator’s Manual
39
17 Green 15 Standby
18 Red 10 Ignition
19 Green 15 Standby
20 Green 15 Standby
3.15 RELAYS
Most of the relays are positioned inside the fuse box. The following table shows the relays and
their Position.
No. Descriptions Position
1
Steering indicator light Top row 1
2
Top 2
3
Floating
Top 3
4
Top 4
5
Parking valve
Top 5
6
Parking indicator light Top 6
7
Horn down 1
8
Parking light Down 2
9
Safety Down 3
10
Delay Down 4
11
Pilot Down 5
12
Starting protection Down 6
Description of the locations of the relay: They are also grouped in one box located on the right
side of the cabin. (see the photo above, The position no. direction is from left to right)
3.16 DOCUMENTS CASE
There is a document case located in the back of seat. It is for keeping operation and maintenance
manual and spare parts book. These two documents are part of the machine and must be always
keep with the machine. This case can provide a clean place for the important documents. It is
convenient for operators to get and deposit the documents, so that they can consult these
documents at any moment. Please keep the operation and maintenance manual and spare parts
book always in this case besides they are in use. It will reduce the possibility of losing
documents.
