5 Operation
46
Display Description Menu selection
Settings – Network (only possible with customer password)
Network settings (Screen 1) Settings – Network – Ethernet
Network settings (Screen 2) Settings – Network – Ethernet –
Only for secondary unit Settings – Network – CAN bus
Only for secondary unit with manual
CAN ID setting: CAN ID request
Settings – Network – CAN bus – CAN ID
Main unit only Settings – Network – CAN bus
Selection at the main unit: type of ID
allocation for the secondary units
Settings – Network – CAN-Bus – Sec-
ondary units
Setting the baud rate Settings – Network – CAN-Bus – Baud
rate
Function test for the CAN connection Settings – Network – CAN-Bus
– Diagnostics
