SUPERSERVER 5018D-FN4T User's Manual
Other Connectors
Universal Serial Bus (USB)
Two Universal Serial Bus 3.0 ports (USB0/1) are located on the I/O rear panel.
Two USB 2.0 headers (USB2/3, 4/5) can provide front panel access. Cables are
not included.
Ethernet Ports (LAN1/LAN2)
Two Gigabit Ethernet ports (LAN1, LAN2), two 10G Base T Ethernet ports (LAN3,
LAN4), and an IPMI LAN port are located on the rear I/O panel to provide network
connections.
VGA
A VGA port is located on the I/O rear panel.
Serial Port
A COM 1 header is located near DIMM slot A1.
Unit Identier Switch
A Unit Identier (UID) Switch and two LED
indicators are located on the motherboard. The
UID Switch is located next to the VGA port on
the rear I/O panel. The rear UID LED (LED7) is
located next to the UID Switch. The front panel
UID LED is located at Pin 7 of JF1.
The UID Indicators assist in locating the system
in a rack of many. When you press the UID
switch, both rear UID LED and front panel UID
LED Indicators turn on. Press the UID switch
again to turn off both LED Indicators.
Note: UID can also be triggered using IPMI.
More information on IPMI is available in the
IPMI User's Guide the Supermicro website.
UID Switch
Pin# Denition
1 Ground
2 Ground
3 Button In
4 Button In
UID LED
Status
Color/State Status
Blue: On Unit Identied
