A+ Server AS -2123BT-Hxxx User's Manual
24
Removing a Node
1. Use the operating system to power down the node.
2. Remove any cables attached to the node
3. Pull down the node release handle and use both handles to slide the node out the
chassis rear.
Figure 3-1. Removing a Node Tray
Node Handle
Node Release Handle
3.2 Accessing the System
Removing a Computing Node Drawer
