A+ Server AS -2123BT-Hxxx User's Manual
Chapter 1
Introduction
1.1 Overview
This chapter provides a brief outline of the functions and features of the AS -2123BT-Hxxx
A+ Server. It is based on the H11DST-B motherboard and the SC217BHQ+-R2K(22/60)BP(2)
chassis. These are Twin
2
chassis with four independent hot-swap computing nodes and
twenty-four 2.5" storage drives.
AS -2123BT-Hxxx Models
System Drive Type Storage Adapter (4) 2U Midplane (1)
2123BT-HTR SATA BPN-ADP-6SATA3-1UB BPN-SAS3-217BHQ
2123BT-HNR NVMe BPN-ADP-6NVME3-1UB BPN-NVME3-217BHQ
2123BT-HNC0R SAS/NVMe hybrid BPN-ADP-6S3008N4-1UB BPN-SAS3-217BHQ-N4
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
Main Parts List
Description Part Number Quantity
Power supply
PWS-2K22A-1R (HTR, HNC0R)
PWS-2K60A-1R (HNR)
2
Power cord
Type IEC (C14 to C13) (HTR, HNC0R)
Type IEC (C19 to C20) (HNR)
2
Fans FAN-0183L4 4
Heatsink SNK-P0062PM 4
Heatsink SNK-P0062PW 4
Rack-mount rails MCP-290-00144-0N 1 set
1.2 Unpacking the System
Inspect the box the in which the server was shipped and note if it was damaged in any way.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and
Be sure to read the precautions and considerations noted in Appendix B.
