Supermicro SUPER P6DBE - SUPER P6 SBM Motherboard Layout

Chapter 1: Introduction
1-17
Figure 1-14. SUPER P6SBM Motherboard Layout
®
J20
COM1
J21
COM2
J32
ATX POWER
J11
J12
J10
U14
1
J17, J18
USB
CPU FAN
J1
JT1
U9
Bank0
Bank1
Bank2
PCI 1
PCI 2
PCI 3
A
G
P
P
O
R
T
U59
JF1
JF2
U29
IR CON PW_ON
RESET
BIOS
IDE LED/KEYLOCK/SPEAKER
1
J22
J16
FLO
PPY
IDE2
ID
E
1
1
1
J15
BZ_ON
JOH
JOH: Overheat LED
JT
3
: T
he
rm
al C
ontrol F
an
JTM
1
WOL
JP11
JBT1: CMOS Clear
JT2
PIIX4E
BX
J19
Parallel
Port
JB1
JB2
JB3
JB4
JBT1
JP20
1
JL1
J36
J8
JJ14
1
9.6"
8.050"
J4
J5 J6
BATTERY
JP12
JT3
BT2
U27
JPWAKE
1
1
——–—— Manufacturer Settings —–———
JBT1: 1-2 (default)
2-3 Clear CMOS
To clear CMOS completely,
disconnect the power source.
JL1: OFF (default)
ON (intrusion)
JP11: 1-2 Auto
2-3 66 MHz
OFF 100 MHz
JP20: 1-2 PIIX CTL PD State
2-3 BIOS CTL PD State (default)
JPWAKE: 1-2 Disabled
2-3 Enabled
WOL: Wake-On-LAN
——–———–————–———–——–——–—
AUDIO
1938
SUPER P6SBM
1
1
1
1
1
1
1
1
1
1
LINE
OUT
LINE
IN
MIC
CD
MPEG
MONO
CD
11
1
1
Note: There are two CD connectors of different sizes. Use the one that matches the size of the connector from your
CD player. The MPEG connector is for use with a DVD decoder card.
9.6"
8.050"
+
-
1
1
J34
PS/2 KB
(bottom)
PS/2 MOUSE
(top)
Note: Some CPU Core/Bus ratios cannot be
selected for processors that have fixed ratios.
CPU
————— CPU Core/Bus Ratio –—————
JB1 JB2 JB3 JB4
x3 ON OFF ON ON
x3.5 OFF OFF ON ON
x4 ON ON OFF ON
x4.5 OFF ON OFF ON
x5 ON OFF OFF ON
x5.5 OFF OFF OFF ON
x6 ON ON ON OFF
X6.5 OFF ON ON OFF
x7 ON OFF ON OFF
x7.5 OFF OFF ON OFF
x8 ON ON OFF OFF
——–—–————————————————
