SUPER P6DBS/P6DBE/P6DBU/P6SBU/P6SBS/P6SBA/P6SBM Manual
1-24
1-4 Solo-1
TM
PCI
Audio
Drive
®
(Standard on P6SBM, OEM option on P6SBU)
The Solo-1 PCI
Audio
Drive feature implements a single-chip PCI audio solu-
tion to provide high quality audio processing while maintaining full legacy
DOS game compatibility. With a dynamic range of over 80 dB, the Solo-1
complies with the Microsoft PC 97/PC 98 specifications and meets WHQL
audio requirements.
The Solo-1 incorporates a microcontroller, an ESFM
TM
music synthesizer, a
3-D stereo effects processor, 16-bit stereo wave ADC and DAC, 16-bit
stereo music DAC, an MPU-401 UART mode serial port, a dual game port, a
hardware master volume control, a serial port interface to an external
wavetable music synthesizer, DMA control logic with FIFO and PCI bus
interface logic. There are three stereo inputs (LINE-IN, LINE-OUT, MIC IN)
and a mono microphone input. For installation information, refer to page 3-
7 in the FAQ section of this manual. When the AudioRack program is
succesfully installed, it will be displayed as shown in Figure 1-16.
Figure 1-16. AudioRack Display
