Preface
About This Manual
This manual is written for system houses, PC technicians and
knowledgeable PC end users. It provides information for the installation and
use of the SUPER P6DBS/P6DBE/P6DBU/P6SBU/P6SBS/P6SBA/P6SBM
motherboard. The SUPER P6DBS/P6DBE/P6DBU/P6SBU/P6SBS/P6SBA/
P6SBM supports Celeron
TM
SEPP 266-433 MHz, Pentium
®
II 233-450 MHz
and 100 MHz FSB speed Pentium III processors up to 700 MHz. (*Note:
Currently, SUPER P6DBE/P6DBU/P6SBU/P6SBA motherboard supports CPU
speeds up to 1GHz with 100MHz FSB speed.)
Pentium III and II processors with the Dual Independent Bus Architecture are
housed in a new package technology called a Single Edge Contact Cartridge
(S.E.C.C.) . This cartridge package and its associated "Slot 1" infrastructure
will provide the headroom for future high-performance processors. Celeron
processors that are packaged in the SEPP (Single Edge Processor Package)
cartridge are also supported by these boards.
Manual Organization
Chapter 1, Introduction, describes the features, specifications and perfor-
mance of the SUPER P6DBS/P6DBE/P6DBU/P6SBU/P6SBS/P6SBA/P6SBM
system board and provides detailed information about the chipset.
Refer to Chapter 2, Installation, for instructions on how to install the Pentium
III/II processor, the Universal Retention Mechanism and the heat sink support.
This chapter also provides you with instructions for handling static-sensitive
devices. Read this chapter when you want to install DIMMs and to mount the
system board in the chassis. Also refer to this chapter to connect the floppy
and hard disk drives, the parallel port and the serial ports as well as the cables
for the power supply, the reset button, the keylock/power LED, the speaker
and the keyboard.
iii
Preface
