9
Chapter 1: Introduction
Figure 1-1. Motherboard Image
Note: All graphics shown in this manual were based upon the latest PCB revision
available at the time of publication of the manual. The motherboard you received may
or may not look exactly the same as the graphics shown in this manual.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Supermicro X11DPL-i and is the answer not in the manual?

Supermicro X11DPL-i Specifications

General IconGeneral
USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Supported DIMM module capacities64GB, 128MB
Memory voltage1.2 V
Supported memory typesDDR4-SDRAM
Maximum internal memory128 GB
Supported memory clock speeds2133, 2400, 2666 MHz
RAID levels0, 1, 5, 10
Wi-FiNo
Ethernet LANYes
Ethernet interface typeGigabit Ethernet
System bus rate10.4 GT/s
Processor manufacturerIntel
Processor thermal power (max)140 W
PCI Express x16 (Gen 3.x) slots2
BIOS typeUEFI AMI
Motherboard chipsetIntelĀ® C621
Motherboard form factorATX
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Depth257.8 mm
Width306.7 mm
