X11DPL-i User's Manual
Motherboard Features
CPU
• This motherboard supports dual Intel Xeon Scalable-SP and 2nd Gen Intel Xeon Scalable-SP processors which offer two Intel®
UltraPath Interconnect (UPI) links of up to 10.4 GT/s
Note: Both CPUs need to be installed for full access to the PCI-E slots, DIMM slots, and onboard controllers.
Refer to the block diagram on page 16 to determine which slots or devices may be affected.
Memory
• Integrated memory controller supports up to 2TB of 3DS LRDIMM/LRDIMM/RDIMM/NV-DIMM DDR4 ECC
2933/2666/2400/2133 MHz memory in 8 memory slots
Note: 2933 MHz memory is supported by 2nd Gen Intel Xeon Scalable-SP (82xx/62xx) series processors only.
DIMM Size
• Up to 128GB at 1.2V
Note 1: Memory speed support depends on the processors used in the system.
Note 2: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
• Intel C621
Expansion Slots
• Two (2) PCI-Express 3.0 x16 slots supported by CPU1 and CPU2
• Three (3) PCI-Express 3.0 x8 slots supported by CPU1
• One (1) PCI-Express 3.0 x4 in x8 supported by CPU1
• M.2 Interface: 1 SATA/PCI-E 3.0 x4
• M.2 Form Factor: 2260, 2280
• M.2 Key: M-Key
BaseBoard Management Controller (BMC)
• ASPEED AST2500 Baseboard Management Controller (BMC) supports IPMI 2.0
• One (1) dedicated IPMI LAN located on the rear IO backpanel
Graphics
• Graphics controller via AST2500 BMC (BaseBoard Management Controller)
Network
• Dual LAN with Marvell 88E1512 Gigabit Ethernet PHY
I/O Devices
• SATA 3.0
• RAID (PCH)
Ten (8 SATA + 2 SATA DOM) SATA ports
• I-SATA0~7
• S-SATA0/1
• RAID 0, 1, 5, 10
Peripheral Devices
• Two (2) USB 2.0 ports on the rear I/O panel (USB 0/1)
• One (1) internal USB 2.0 header for two (2) USB front panel support (USB 2/3)
• One (1) Type A USB 3.0 connector (USB 4)
• One (1) internal USB 3.0 header for two (2) USB front panel support (USB 5/6)
Motherboard Features
