Supermicro X9DRW-iF User Manual

1-8
X9DRW-3F/X9DRW-iF Motherboard User’s Manual
SAS/SATA/SCU Connection
• Eight (8) SAS/SATA Connections 0~3, 4~7 (For
X9DRW-3F)
RAID 0, 1, 10
• Four (4) SATA Connections 0~3 (For X9DRW-iF)
RAID 0, 1, 5, 10
IPMI 2.0
• IPMI 2.0 supported by the Renesas BMC
Serial (COM) Port
• Two (2) Fast UART 16550 connections: 9-pin RS-
232 port
Note: COM2 does not support modem func-
tion)
VGA
• Backplane VGA Port 1
Peripheral
Devices
USB Devices
• Four (4) USB ports on the rear I/O panel (USB 0/1,
USB 2/3),
• Two (2) Front Panel USB headers (USB 4/5)
BIOS
• 16 MB AMI BIOS
®
Flash EEPROM
• APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0/4.0, USB Key-
board, Plug & Play (PnP) and SMBIOS 2.3
Power
• ACPI/ACPM Power Management
Management
• Main switch override mechanism
• Power-on mode for AC power recovery
• Keyboard Wake-up from Soft-off
• Intel
®
Intelligent Power Node Manager (Available
when the NMView utility is installed in the system)
• Management Engine
PC Health
CPU Monitoring
Monitoring
• Onboard voltage monitors for onboard chipset,
memory, processors, standby power, and other criti-
cal components.
• CPU 6-Phase switching voltage regulator
• CPU/System overheat LED and control
• RAID (Linux) RAID 0, 1, 10

Supermicro X9DRW-iF Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Memory voltage	1.35, 1.5 V
Memory channels	Dual-channel
Maximum RDIMM memory	512 GB
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	800, 1066, 1333, 1600 MHz
Maximum UDIMM memory	128 GB
Number of DIMM slots	16
Supported RDIMM module capacity	16GB, 1GB, 2GB, 32GB, 4GB, 8GB
Supported UDIMM module capacity	1GB, 2GB, 4GB, 8GB
BIOS type	AMI
ACPI version	4.0
BIOS memory size	128 Mbit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I350
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Matrox G200
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	8 GT/s
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Processor manufacturer	Intel
Processor thermal power (max)	135 W
Processor number of cores supported	6, 8
Component for	Server
Motherboard chipset	Intel® C602
Sustainability certificates	RoHS

Weight and Dimensions

Depth	330 mm
Width	305 mm
