Supermicro X9DRW-iF User Manual

Chapter 1: Overview
1-15
offers a 4-way full-associative instruction TBL (Translation Lookaside Buffer) and a
64-way full-associative shared TBL. The memory management unit, which is embed-
ded on the chip, provides access to 4 Gb virtual address space. In addition, this
controller also supports 32 Kb on-chip SRAM, allowing for faster access which is
especially critical to time-sensitive, high-density/high-performance server platforms.
The BMC supports VGA Graphic Cores for remote video displaying and editing. It
also provides a video data compressor for Keyboard/Video/Mouse (KVM) support if
keyboard/mouse are installed in the system. With two Ethernet controllers built in,
the BMC controller supports USB media hosting, an LPC bus interface, an I
2
C bus
interface, a NAND Flash Timer Interface and serial communication interfaces. The
BMC controller offers great system enhancement at a low cost.
BMC Subsystem Features
•CPU speed: 576MHz
•System Memory: 256MB
•Flash Memory: 32MB
•Network connections: Two Gigabit connections (One dedicated LAN connection
and one shared LAN with an on-board LAN controller)
•Resolutions:
•Supports 1680 x 1200 resolution at 32 bpp and 75 Hz
•Supports 1680 x 1050 wide screen resolution at 32 bpp and 60 Hz
Note: The term "IPMI controller" and the term "BMC controller" can be
used interchangeably in this section.

Supermicro X9DRW-iF Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Memory voltage	1.35, 1.5 V
Memory channels	Dual-channel
Maximum RDIMM memory	512 GB
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	800, 1066, 1333, 1600 MHz
Maximum UDIMM memory	128 GB
Number of DIMM slots	16
Supported RDIMM module capacity	16GB, 1GB, 2GB, 32GB, 4GB, 8GB
Supported UDIMM module capacity	1GB, 2GB, 4GB, 8GB
BIOS type	AMI
ACPI version	4.0
BIOS memory size	128 Mbit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I350
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Matrox G200
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	8 GT/s
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Processor manufacturer	Intel
Processor thermal power (max)	135 W
Processor number of cores supported	6, 8
Component for	Server
Motherboard chipset	Intel® C602
Sustainability certificates	RoHS

Weight and Dimensions

Depth	330 mm
Width	305 mm
