Supermicro X9DRW-iF User Manual

Chapter 1: Overview
1-7
Motherboard Features
CPU
• Dual Intel
®
E5-2600(v2) Series Processors (Socket
R LGA 2011); each processor supports two full-width
Intel QuickPath Interconnect (QPI) links of up to 8.0
GT/s per QPI link and with data transfer rate of up to
16 GB/s direction peak bandwidth per port.
Note: For Intel E5-2600(v2) processor support,
BIOS version 3.0 or above is required.
Memory
• Integrated memory controller supports up to 1 TB
of Load Reduced (LRDIMM), 512 GB of Registered
(RDIMM) or 128 GB of Unbuffered (UDIMM) ECC/
Non-ECC DDR3 800/1066/1333/1600/1866 MHz
240-pin 4-channel memory modules in 16 DIMM
slots.
Note 1: 1866 MHz memory speed is dependent
on Intel E5-2600v2 CPUs.
Note 2: For the latest memory updates, please
refer to the Tested Memory List posted on our
website (http://www.supermicro.com/products/
motherboard).
• Virtualization: VT-x, VT-d, and VT-c
Chipset
• Intel® PCH 606/602 Chipset
Expansion
• One (1) SMC-Proprietary PCI-E 3.0 x16 slot (Right)
(SXB2) (See Note 2 on Page 1-5),
• One (1) SMC-Proprietary PCI-E 3.0 x16 + x16 slot
(Left) (SXB1B) (See Note 1 on Page 1-5),
• Two (2) SMC-Proprietary SPEC slot (SXB1A/
SXB1C) (See Note 1 on Page 1-5.)
Slots
Graphics
• Renesas BMC Video Controller
Network
• One Intel I350 Gigabit Dual-Channel Ethernet Con-
troller for LAN1/LAN2 ports.
• Renesas Baseboard (BMC) Controller (SH7757)
supports IPMI_LAN 2.0
I/O Devices
SATA Connections
• SATA Ports Six (6) SATA ports total: two
SATA 3.0 and four SATA 2.0
ports
• RAID (Win-
dows)
RAID 0, 1, 5, 10

Supermicro X9DRW-iF Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Memory voltage	1.35, 1.5 V
Memory channels	Dual-channel
Maximum RDIMM memory	512 GB
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	800, 1066, 1333, 1600 MHz
Maximum UDIMM memory	128 GB
Number of DIMM slots	16
Supported RDIMM module capacity	16GB, 1GB, 2GB, 32GB, 4GB, 8GB
Supported UDIMM module capacity	1GB, 2GB, 4GB, 8GB
BIOS type	AMI
ACPI version	4.0
BIOS memory size	128 Mbit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I350
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Matrox G200
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	8 GT/s
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Processor manufacturer	Intel
Processor thermal power (max)	135 W
Processor number of cores supported	6, 8
Component for	Server
Motherboard chipset	Intel® C602
Sustainability certificates	RoHS

Weight and Dimensions

Depth	330 mm
Width	305 mm
